DK-LOK V23 SERIES PLUG VALVES

Mã sản phẩm: DK-LOK V23

Giá: Liên hệ

DK-LOK V23 SERIES PLUG VALVES

Mô tả sản phẩm

VAN BI DK-LOK V23

DK-LOK V23 SERIES PLUG VALVES

DK-LOK V23DK-LOK V23

Thông tin sản phẩm: DK-LOK V23

  • Differential pressure is limited to maximum 150 psig (10.3bar) when reverse flow occurs.
  • Throttling reverse flow may damage O-ring.

Features:

  • Quarter-turn operation
  • Unique forward flow throttling
  • Low torque operation
  • Unidirectional flow

Materials of Construction



Component

Valve Body Materials

Stainless Steel

Brass

Grade/ASTM Specification

1. Body

SS316/ A479 or A276

Brass / B16

2. Plug

PTFE-coated SS316/ A479 or A276

PTFE-coated Brass / B16

3. O-ring

PTFE-coated FKM

4. Handle

Nylon

5. Pin

SS316/A276

6. Snap ring

Stainless Steel

 - Technical Data

Series

Valve Material

Pressure Rating

Temperature Rating

Plug Orifice mm (in.)

psig

bar

V23A

SS316



3000



206



-10 to 400 F

(-23 to 204 C)

4.4 (.17)

Brass

V23B

SS316

7.2 (.28)

Brass

2000

137

Operation

  • D-pro plug valves provide positive shut-off, high flow capacity, and quick quarter-turn operation.
  • D-pro plug valve provides flow throttling capability

Các sản phẩm liên quan: V23A-F-2N-S, V23A-F-4N-S, V23A-F-4R-S, V23A-M-2N-S, V23A-M-4N-S, V23A-MF-4N-S, V23A-MD-4N4T-S, V23A-D-2T-S, V23A-D-4T-S, V23A-D-6T-S, V23A-D-6M-S, V23B-F-6N-S, V23B-F-8N-S, V23B-F-8R-S, V23B-M-8N-S, V23B-D-6T-S, V23B-D-8T-S, V23B-D-8M-S, V23B-D-10M-S, V23B-D-12M-S
