HELS HLC-100 CẢM BIẾN MỨC

Mã sản phẩm: HELS HLC-100

Giá: Liên hệ

It has four different measurement probe and an electronic unit and so without any other controlunit it allows to controlby itself.

Mô tả sản phẩm

HELS HLC-100 CẢM BIẾN MỨC

HELS HLC-100 LEVEL SENOR

HELS HLC-100

Thông tin sản phẩm: HELS HLC-100
ISS 04 Level Sensor is designed for controlling conductive measurement principle. It has four different measurement probe and an electronic unit and so without any other controlunit it allows to controlby itself. The sensor has two different conductive level measurement and four different control function, which are selecttable by user. It can be in min. 1 S/cm and over conductive liquids.

Mounting Position: Vertical (into boiler or with by-pass tube)
Process Connection: 1″ BSP
Working Pressure: 32 Barg@280C
Case: Aluminium Casting (Electrostatic Painted)
Connection Material: 1.4571 Stainless Steel
Electrode Isolation: PTFE
Electrode Material: 1.4571 Stainless Steel
Case Instulatıon Material: PTFE
Pipe Material: Stainless Steel
Electrode Lenght: 500 mm, 1000 mm, 1500 mm
Electrode Diameter: 4 mm
Cable: 5×0.75 mm2 Silicon Isolated
Cable Entry: 3 pieces PG11 Chromed Brass
Supply: 220 – 240 VAC
Electrode Voltage: 6V max.
Sensivity: 1uS/cm min. veya 30 uS/cm min. selectable
Outout: Volt-free contacts
Relay: Schrack-RY211024 or equivalent
Relay Delay: 3 sn
Ambient Temperature: 700C
Protection Class: IP 65
Weight: 2,9 kg (for L:1000mm )

Thông số kỹ thuật: HELS HLC-100

HELS HLC-100 Installation Position : Vertical ( into the boiler or py-pass tube)Process connection : G 1"
Operating Pressure : 32 Barg → 238˚C
Protection : cast aluminum (electrostatic painted)
Connection Material : 1.4571 Stainless Steel
Electrode Isolation : PTFE
Electrode Material : 1.4571 Stainless Steel
Middle Part Material : PTFE
Middle Pipe Material : Stainless Steel
Electrode Length : 500 - 1000 - 1500mm
Electrode Diameter : 4mm
Cable : Silicone Isolated 5x0,75mm 2
Cable Entry : 3 Piece Pg 11 chrome-plated brass
Supply : 220-420 Vac (Stnd.) Or
Followed electrode resistance : 6V Max.
Sensitivity : 1us / cm min. or 30us / cm min. eligible
Output : Volt-free Contacts
Relays : RY Schrack 2110124 or equivalent
Relay Delay : 3 SN
Environmental Temperature : 70˚C
Protection Class : IP 65
Weight : 2,9 kg ( L: 1000mm için )
