HELS HTD-50 BẪY HƠI NHIỆT ĐỘNG HỌC
HELS HTD-50 THERMODYNAMIC STEAM TRAP

Thông tin sản phẩm:

HTD-50 thermodynamic steam trap designed for discharging condansate and depends on condansate load in system, it can work intermittently. Body material and inner parts are stanless steel. Seat and disk material is hardened.

Operating surfaces precision machined for perfect leakproofing and HTD-50 has inner filter which can be maintained very easily.Spare parts are also available.
Connection Types

1/2”-3/4”- 1” Screwed BSP or NPT
½””- 3/4”-1” Socket weld ANSI B16.11
DN15, DN20, DN25 EN 1092-1 Flanged

Certification: Please ask EN 10204 3.1 certification while ordering.

Application

– Iron Machines
– Drying Units
– Pressing Units
– Steam Jacket Pipelines

Capacity Diagraphm: Differantial pressure is the difference between inlet pressure to outlet pressure of steam trap. Max. operating backpressure must not exceed 80% of the upstream pressure.

Ordering: HTD-50 BSP ½”
Please inform connection type, steam pressure, steam temperature,
condansate load, delta P.

Thông số kỹ thuật: HELS HTD-50

• Body : SS AISI 420
• Cover : SS AISI 416

• Filter : SS AISI 304
• Disc: SS AISI 416
• Max. Working Pressure PMO : 42 Bar
• Max. Working Temperature TMO : 400 °C
