Warranty

Up to 15-year limited warranty

Rangedown

Up to 150:1

Communication Protocol

4-20 mA HART, WirelessHART®, FOUNDATION™ Fieldbus

Measurement Range

Up to 150 psi (10.34 bar) Differential with maximum working pressure up to 15,000 psi (1034 bar)

Process Wetted Material

Alloy C-276

Diagnostics

Basic Diagnostics, Power Advisory Diagnostics, Advanced Diagnostics

Certifications/Approvals

SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE, hazardous location, see full specs for complete list of certifications

Features

SuperModule design withstands static lines pressures of up to 15000 psi (1,034 bar)

Multivariable transmitter capable of differential pressure and temperature measurements

Innovative, compact, coplanar platform reduces up to 60% of the weight versus today’s high pressure transmitters

All-welded, hermetic design of the SuperModule platform resists overpressure and line pressure effects to ensure 0.055% accuracy

Robust design, backed by 10-year stability, withstands the harshest production environments

Integrates seamlessly with 4-20 mA HART®, WirelessHART®, FOUNDATION™ fieldbus protocols for application flexibility

Advanced diagnostics offer comprehensive diagnostic coverage from the process to the transmitter to the host

SIL 2/3 certified to IEC 61508 by an 3rd party and prior-use certificate of FMEDA data for safety installations
