Warranty

Up to 5-year limited warranty

Rangedown

Up To 100:1

Communication Protocol

4-20 mA HART®, FOUNDATION™ Fieldbus

Measurement Range

Up to 300 psig (20,7 bar) Gage, Up to 150 psia (10,3 bar) Absolute

Process Wetted Material

316L SST mechanically polished and electropolished to Ra < 15 µ-in. (0.38 µ-m)

Diagnostics

Basic Diagnostics, Power Advisory Diagnostics

Certifications/Approvals

3A, EHEDG, ASME-BPE, see full specs for complete list of certifications

Features

Connects to various industry standard sanitary fittings

Meets 3-A, EHEDG and ASME-BPE standards to meet industry-specific requirements

Polished stainless steel housing is free of voids and crevices to ensure easy cleaning and wipe downs

Offers best-in-class performance of 0.065% of span and 5-year stability

Withstands washdown conditions (IP66/68 rated) for long-term performance and durability

Local Operator Interface (LOI) for simple, local commissioning on-site without the use of extra tools

Sensor technology provides excellent batch repeatability up to ±0.02% Upper Range Limit for 60 batches

Power Advisory diagnostics detect degraded electrical loop integrity issues to prevent unplanned downtime
