Specifications

Warranty

Up to 15-year limited warranty

Rangedown

Up to 200:1

Communication Protocol

4-20 mA HART, WirelessHART®, FOUNDATION fieldbus

Measurement Range

Up to 10000psi (689,47 bar) Gage, Up to 10000psia (689,47 bar) Absolute

Process Wetted Material

316L SST, Alloy C-276

Diagnostics

Basic Diagnostics, Power Advisory Diagnostics, Advanced Diagnostics

Certifications/Approvals

SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications

Features

No-equal, scalable architecture optimizes performance, functionality and process connections

Designed with direct threaded connections or manifolds and remote seals for a quick and cost-effective installation

Ultra and Classic Performance class enhances process control

15-year stability and 200:1 rangedown produce reliable measurements and wide application flexibility

Piezoresistive sensor technology allows calibrated spans from 0.3 to 10000 psi (20.7 mbar to 689 bar)

Seamless integration with 4-20 mA HART®, WirelessHART®, FOUNDATION™ fieldbus protocols for application adaptability

SIL 2/3 certified to IEC 61508 by a 3rd party and prior-use certificate of FMEDA data for safety installations

Advanced diagnostics offer diagnostic coverage to detect electrical loop issues and abnormal process conditions

Remote display offers easy access to device display and loop connection
