Warranty

Up to 12-year limited warranty

Rangedown

Up To 100:1

Communication Protocol

Modbus®, BSAP/MVS

Measurement Range

Up to 2000 psi (137,89 bar) differential

Process Wetted Material

316L SST, Alloy C-276

Diagnostics

Basic Diagnostics

Certifications/Approvals

NACE®, hazardous location, see full specs for complete list of certifications

Features

Modbus transmitter allows multivariable measurements in combinations of differential and static pressure and temperature

Primary elements available as assemble-to options for simple installation and commissioning

Optimized sensor technology captures large fluctuations in flow rate that commonly occur in oil and gas production applications

Enhanced for flow is a ±0.05% of reading specification for increased accuracy

LCD display provides data right at the measurement point for further insight into the process

Callendar-Van Dusen sensor matching improves temperature accuracy enabling best-in-class flow calculations

Reverse wiring protection guards the device from incorrect wiring

All-welded, SuperModule™ design offers industry-leading accuracy in harsh environments and applications

Low power consumption helps reduce the size and amount of solar panels and battery banks for cost-efficiency
