Specifications

Warranty

Up to 15-year limited warranty

Rangedown

Up to 200:1 (14:1 flow turndown)

Measurement Range

Up to 1000 inH2O (2,48 bar) differential, Up to 3626 psia (250,00 bar) absolute, Up to 3626 psig (250,00 bar) gage

Line Size

2 to 96 in. (50 to 2440 mm)

Output

Differential pressure, static pressure, process temperature, scaled variable, mass flow, volumetric flow, energy flow

Communication Protocol

4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus

Process Wetted Material

316 SST, Alloy C-276

Diagnostics

Basic Diagnostics, Power Advisory Diagnostics, Advanced Diagnostics

Certifications/Approvals

SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE, hazardous location, see full specs for complete list of certifications

Features

Designed with built-in flow calculations for direct reporting of fully-compensated mass flow

Patented T-shape sensor creates a fixed separation point for DP signal improvement over a wider flow rate

Advanced diagnostics provide diagnostic coverage to detect abnormal process conditions and electrical loop issues

Callendar-Van Dusen sensor matching improves temperature accuracy enabling best-in-class flow calculations

Ultra for Flow performance class enables optimized flow measurement with a ±0.04% of reading accuracy

T-shape Annubar design features very low permanent pressure loss

Integral thermowell of sensor adds process temperature measurement without additional pipe penetrations

All-welded, SuperModule™ design offers industry-leading accuracy in harsh environments and applications

Flowmeters come fully configured, leak-tested and ready to install right out of the box for fast installation

Sensor stagnation zone positioned to reduce noise, measurement inaccuracies and keeps particulates from clogging

SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations
