Rosemoun 2240S Multi-input Temperature Transmitter

Rosemoun 2240S Multi-input Temperature Transmitter

Mã sản phẩm: 20181102-120

Giá: Liên hệ

The ultra-stable Rosemount 2240S is approved for demanding custody transfer applications, which require very accurate temperature measurements for net standa...

Mô tả sản phẩm

Specifications

Resolution: ± 0.1 °C (± 0.1 °F) according to API chapter 7 and 12.

Number of Spot Elements: Up to 16 RTD spot elements:
• 3-wire common return or individual wiring.
• 4-wire individual wiring.

Sensor Type: Supports Pt-100 (according to IEC/EN60751, ASTM E1137) and Cu-90.

Communication Protocol: Foundation™ Fieldbus for connection to Rosemount 2410 with self-configuring Tankbus or any Foundation™ Fieldbus host system.

Custody Transfer Approval: OIML R85:2008, and national certifications such as PTB, NMi etc.

Metrology Sealing: Yes.

Power Supply: • FISCO: 9.0 - 17.5 VDC polarity insensitive (for example from 2410 Tank Hub).
• Entity: 9.0 - 30.0 VDC polarity insensitive.

Ambient Temperature: -40 to +70 °C (-40 to +158 °F).
Minimum start-up temperature is -50 °C (-58 °F).

Features

Get ultra-stable temperature measurement for precise inventory calculations and custody transfer for API chapter 7.3 compliance.
Obtain outstanding temperature conversion accuracy of ±0.05 °C (±0.09 °F).
Connect up to 16 three- or four-wire temperature elements.
Include integrated water level sensor.
Benefit from convenient and safe installation with two-wire IS bus power supply.
