Warranty

Up to 15-year limited warranty

Rangedown

Up to 200:1

Communication Protocol

WirelessHART®

Measurement Range

Up to 2000psi (137,89 bar) Differential, Up to 2000psig (137,89 bar) Gage, Up to 4000psia (275,79 bar) Absolute

Process Wetted Material

316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated Alloy 400, Gold-plated 316L SST

Diagnostics

Basic Diagnostics

Certifications/Approvals

NSF, NACE, hazardous location, see full specs for complete list of certifications

Update Rate

1 sec. to 60 min., user selectable

Power Module Life

Up to 10-year life, field replaceable (order separately)

Wireless Range

Long range (225 m), extended range (800 m), remote (225 m) and high-gain remote (1 km)

Features

WirelessHART® technology is secure, stable, cost-effective and delivers >99% data reliability for process automation

Patented Rosemount coplanar technology offers optimized performance as a pressure, DP Flow and DP Level solution

Transmitter arrives fully assembled and leak tested for simple installation and maintenance

Best-in-class, scalable architecture enhances performance, functionality and process connections

All-welded hermetic SST SuperModule™ platform resists overpressure and line pressure effects to ensure 0.025% accuracy

Ultra and Ultra for Flow performance classes deliver 15-year stability and 15-year limited warranty

200:1 rangedown produce reliable measurements and wide application flexibility

SmartPower™ module provides up to 10-year maintenance-free operation and field replacement without transmitter removal

Easy installation enables quick instrumentation of measurement points without the cost of wiring
